MS-120

Electric Performance Index
Output Power:80W + 80W (UL / 8 Ω )    48W + 48W (TR / 8Ω )
Distortion:≤0.6%(1KHz 60W )
Frequency Response:10Hz-58KHz (-2dB )
SNR:≥92dB (A)
Output Impedance:8Ω or 4Ω
Power Consumption:220W
Input sensitivity:≤260mV
Tube:TUNG-SOL KT120 × 4  6SN7EH × 2 12AX7EH × 2
Weight:55 Kg
Net Weight:48 kg
Volume:385mm(L) × 405mm(W) × 455mm(H)
  yaqin@fsyaqin.com

Details display

MS-500B
MS-120
MS-500B
MS-120
MS-500B
MS-120

Test report

3C certification
3C certification
CE certificate
CE certificate
650B glory
Get good title
2012 hifi audio Awards
2012 hifi audio Awards

Our Core Advantages

Industry experience

Industry experience

01
27 years of experience in the production of tube power amplifiers ;OEM for many well-known brands, products are sold to more than 40 places at home and abroad
Quality Assurance

Quality Assurance

02
Passed 3C certification, CE certification, CB certification, in line with HIFI standards,
and won a number of HIFI audio awards
Prompt Delivery

Prompt Delivery

03
The company has a 5000㎡ production workshop, 7 automated production
 lines, which are equipped with metal casing stamping processing, CNC numerical control processing, transformer production and product assembly workshops, etc.
After-sales Service

After-sales Service

04
Implement "three guarantees" after-sales service, free guidance for use
One year warranty for switchboard and ten years for transformer

Hot product recommendation

MS-88

MS-88

Maximum output power: 50W*2 (8 ohms, ultra linear, 1KHz, THD=5%) 25W*2 (8 ohms, tri-pole, 1KHz, THD=5%) Total harmonic distortion: ≤1% (at 35W output, 1KHz) Signal-to-noise ratio: ≥91dB (A-weighted) Input sensitivity: ≤300mV Frequency response: 10Hz~75KHz (-2dB) Load impedance: 4Ω or 8Ω Maximum power consumption: 300W Electronic tube: KT-88*4, USSR 6H8C*2, ECC83/12AX7*1 Gross weight approx.: 27.5kg Net weight approx.: 24kg Dimensions: W400mm H219mm D363mm
MS-34B

MS-34B

Output Power:UL38W×2(8Ω) Frequency Response:10Hz--48KHz(-2dB) Distortion:≤1.0% SNR:≥90dB(A) Input Sensitivity:Intergrated:≤260mV Maximum Power Consumption:≤250W Tube:EL34 x 4  6N8P x 2 6N9P x 1   Gross Weight:about 25.5 kg Size:(W)400mm(D)355mm(H)220mm
MC-100B

MC-100B

Output Power: 25W+25W (8Ω) three-pole (TR) connection    50W+50W (8Ω) ultra-linear (UL)  connection Frequency response: 5Hz-80KHz (-2dB)  Distortion: ≤0.5% (at 35W)  Signal to noise ratio: ≥91dB (A) Input sensitivity: combined type ≤ 0.25V Maximum power consumption: ≤370W  Electronic tube: KT88×4 6N8P×4 12AX7B×2  Gross weight: about 31 kg
  MS-84L

  MS-84L

Output power: 2x12W (4Ω-8Ω)  Harmonic distortion: ≤2%  Signal to noise ratio: ≥80db (A)  Frequency response: 6HZ-90KHz  Input sensitivity: 250mV  Input signal level: ≤300mv  Maximum power consumption: ≤90W  Tube: 6P14*4 12AX7B*2
MC-13S

MC-13S

Output power: 40W + 40W (8Ω)  Distortion: ≤0.9%(28W)  Frequency response: 10Hz -76KHz (-2dB)  Signal to noise ratio: ≥85dB (A weighting)  Power consumption: ≤220W  Sensitivity: ≤0.26V  Electronic tube: EL34×4 or 6CA7T×4 12AT7×4  Gross weight: 22Kg  Volume: length 470mm × width 315mm × height 175mm
MS-88

MS-88

Maximum output power: 50W*2 (8 ohms, ultra linear, 1KHz, THD=5%) 25W*2 (8 ohms, tri-pole, 1KHz, THD=5%) Total harmonic distortion: ≤1% (at 35W output, 1KHz) Signal-to-noise ratio: ≥91dB (A-weighted) Input sensitivity: ≤300mV Frequency response: 10Hz~75KHz (-2dB) Load impedance: 4Ω or 8Ω Maximum power consumption: 300W Electronic tube: KT-88*4, USSR 6H8C*2, ECC83/12AX7*1 Gross weight approx.: 27.5kg Net weight approx.: 24kg Dimensions: W400mm H219mm D363mm
