Product Center

MC-100B

MC-100B

Output Power: 25W+25W (8Ω) three-pole (TR) connection    50W+50W (8Ω) ultra-linear (UL)  connection Frequency response: 5Hz-80KHz (-2dB)  Distortion: ≤0.5% (at 35W)  Signal to noise ratio: ≥91dB (A) Input sensitivity: combined type ≤ 0.25V Maximum power consumption: ≤370W  Electronic tube: KT88×4 6N8P×4 12AX7B×2  Gross weight: about 31 kg
MC-10T

MC-10T

Electric Performance Index Output Power:45W + 45W (8Ω) Distortion:≤0.35% Frequency Response:5Hz-54KHz (-2dB)  SNR:≥88dB (A) Load Impedance:8Ω-4Ω Maximum Power Consumption:220W Input sensitivity:≤200mV Tube:EL34B × 4 12AX7/ECC83 × 2 12AU7/ECC82 × 2 Gross Weight:about 21kg Volume:470mm(L) × 315mm(W) × 175mm(H)
MS-77T

MS-77T

Output power: 40W + 40W (8Ω) Distortion: ≤0.5% (1KHz) Frequency response: 5Hz -68kHz Signal-to-noise ratio: ≥88dB (A weighting) Input sensitivity: ≤0.23V (1KHz) Electronic tube: 7027B × 4 6J1 × 8 Load impedance: 4Ω-8Ω Power consumption: about 250W
  MS-84L

  MS-84L

Output power: 2x12W (4Ω-8Ω)  Harmonic distortion: ≤2%  Signal to noise ratio: ≥80db (A)  Frequency response: 6HZ-90KHz  Input sensitivity: 250mV  Input signal level: ≤300mv  Maximum power consumption: ≤90W  Tube: 6P14*4 12AX7B*2
MS-6P14

MS-6P14

Maximum output power: 11W × 2 (8Ω) Frequency response: 10Hz-65KHz (-2dB) Distortion: ≤0.7% Signal to noise ratio: ≥90dB (A weighting) Input sensitivity: ≤320mV Maximum power consumption: ≤120W Tube: 12AX7/ECC83 x 1, 12AU7/ECC82 x 1, EL84/6p14/6n14nx 4 Net weight: about 11.5 kg Gross weight:13.5 kg Size:220*295*250(mm)
MC-13S

MC-13S

Output power: 40W + 40W (8Ω)  Distortion: ≤0.9%(28W)  Frequency response: 10Hz -76KHz (-2dB)  Signal to noise ratio: ≥85dB (A weighting)  Power consumption: ≤220W  Sensitivity: ≤0.26V  Electronic tube: EL34×4  12AX7(ECC83)×2 12AU7(ECC82)×2 Gross weight: 22Kg  Volume: length 470mm × width 315mm × height 175mm
